1. Small size, SMT metal encapsulated active crystal oscillator, size: 5.0 × three point two × 1.2mm.
2. Working voltage: 1.8V~3.3V.
3. Supports three state functionality.
4. Reel ribbon packaging, can be used for automatic installation and reflow soldering.
5. CMOS output, wide frequency output range 32.768kHz~220MHz
6. High stability, low jitter, and low power consumption.
7. Green and environmentally friendly products, certified by RoHS and Pb Free.
8. The SMD 5032 active crystal oscillator is mainly used in servers, fiber optics, computers and computer peripherals, network communication, digital television, gaming equipment, testing instruments, automotive electronics, industrial computers, broadcasting and television, consumer electronics and other electronic products and applications.
| model | NSP53 5032 active crystal oscillator | ||||
| Material code | NSP53 | ||||
| type of output | CMOS | ||||
| Output load | 15pF, or customized | ||||
| Oscillation mode | Fundamental/Third harmonic | ||||
| working voltage | 1.8V~3.3V | ||||
| frequency range | 32.768kHz~220MHz | ||||
| Adjusting frequency difference | ± 25ppm~± 50ppm | ||||
| working temperature | -20~70 ℃ (-10~60 ℃, -40~85 ℃), or customized | ||||
| Output voltage Vol max/Voh min | 01VDD/0.9VDD | ||||
| Rise/Fall Time | 8 ns max | ||||
| Duty cycle | 40-60% | ||||
| Start time | 5 ms max | ||||
| Storage temperature | -55-125 ℃, or customized | ||||
| Phase jitter (12KHz~20KHz) | 1 ps max | ||||
| Aging rate (25 ℃) | ± 3ppm/year max | ||||
| Product size (mm) | five × three point two × one point two | ||||
| Packaging quantity | 1000pcs/ volume | ||||
