1. Single port resonator
2. Ceramic packaging for surface mount technology (SMT)
3. Package size 5.0 × three point five × 1.5mm
4. Electrostatic sensitive devices (ESD)
5. Encapsulation code QCC8C
6. Low insertion loss
7. Compliant with RoHS standards/lead-free
8. Frequency range from 299MHz to 868MHz
9. Application: Automotive electronics, remote control, alarm. Security, Internet of Things, smart cities, and more
| Part Number | Center Frequency (MHz) | Frequency Tolerance | Insertion Loss (dB) max. | Package Code |
| R299 | 299.000 |
±30KHz / ±75KHz |
1.2 | QCC8C |
| R303.825 | 303.825 |
±30KHz / ±75KHz |
1.5 | QCC8C |
| R303.875 | 303.875 |
±30KHz / ±75KHz |
1.4 | QCC8C |
| R304.3 | 304.300 |
±30KHz / ±75KHz |
1.1 | QCC8C |
| R315 | 315.000 | ±30KHz / ±75KHz | 1.3 | QCC8C |
| R330 | 330.000 |
±30KHz / ±75KHz |
1.6 |
QCC8C |
| R358 | 358.000 |
±30KHz / ±75KHz |
1.0 |
QCC8C |
| R370 | 370.000 |
±30KHz / ±75KHz |
1.4 |
QCC8C |
| R390 | 390.000 |
±30KHz / ±75KHz |
1.4 |
QCC8C |
| R403.22 | 403.220 |
±30KHz / ±75KHz |
1.5 |
QCC8C |
| R403.55 | 403.550 |
±30KHz / ±75KHz |
1.3 |
QCC8C |
| R433 | 433.920 |
±30KHz / ±75KHz |
1.2 | QCC8C |
| R434.42 | 434.42 |
±30KHz / ±75KHz |
1.3 |
QCC8C |
| R868.35 | 868.350 |
±75KHz / ±150KHz |
1.0 |
QCC8C |
